The Orion-Tr Smart DC-DC charger is a professional DC to DC adaptive 3-stage charger with built-in Bluetooth for lead acid and lithium battery systems.

For use in dual battery systems in vehicles or on boats where the (smart) alternator and the start battery are used to charge the service battery. The unit can be monitored and programmed via Bluetooth and can be remotely controlled via a remote on/off switch and has an engine running detection mechanism.

The Orion-Tr Smart charger can be used in 12V or 24V systems and is suitable for both lead acid and lithium batteries. Models are available up to 400W and unlimited multiple units can be connected in parallel to increase output power.

Suitable for high temperatures up to 55°C with a full rated output up to 40°C.

Key specifications

• Input voltage range: 16–35V

• Output voltage: 12.2V (adjustable 10–15V)

• Continuous output current: 30A  |  Maximum output current: 45A

• Continuous output power: 430W (25°C) / 360W (40°C)

• Max efficiency: 88%

• Galvanic isolation: 200VDC

• Bluetooth built-in, monitor and configure via the VictronConnect app

• Protection category: IP22 (connection area), IP43 (electronic components)

• Operating temperature range: -20°C to 55°C

• Dimensions: 130 x 186 x 80mm  |  Weight: 1.8kg

• Colour: Blue (RAL 5012)

Warranty

Standard warranty: 5 years (extendable to 10 years for an additional 10% fee – contact us for a quote). Warranty exceptions: lead acid batteries 2 years, lithium batteries 3 years.
